Datasheet
Epoxy Resin Injection Syringe
Producer: Iran Concrete Technical Clinic Group (Clinic Beton Iran, RBS-CONTECH)
Brand: RBS-CONTECH
Websites: https://www.clinicbeton.com | https://www.rbs-contech.com
Product Description
The Epoxy Resin Injection Syringe is a practical single-use or reusable device designed for accurate, low-pressure injection of epoxy resins into fine cracks, voids, micro-holes, and delamination zones in concrete, stone, masonry, and other substrates. This tool ensures controlled dosing, targeted filling, and easy access to narrow or delicate repair zones – especially useful for precise repairs and consolidation in restoration and structural applications.
Technical Specifications
| Property | Value / Description |
|---------------------------|---------------------------------------------------|
| Product Type | Manual Injection Syringe for Epoxy Resin |
| Material | High-grade Polypropylene (PP) / Polyethylene |
| Capacity | 50 ml, 100 ml, 150 ml, 200 ml (custom on request) |
| Plunger Type | Ergonomic, leak-proof with precise control |
| Nozzle | Tapered, removable, fits most crack widths |
| Tip Diameter | 1.2 mm to 5 mm (interchangeable options) |
| Length | 12 – 22 cm (depending on capacity) |
| Pressure Range | Up to 2 bar (manual hand force) |
| Chemical Compatibility | Resistant to epoxy resin, polyurethane, acrylic |
| Reusability | Single-use (recommended) or reusable with care |
| Sterility | Non-sterile; clean and dry prior to use |
| Storage Conditions | Cool, dry, away from direct sunlight |
| Standards Compliance | Internal QC, ISO 9001 (factory) |
Key Features
Suitable for precise, controlled injection of epoxy, polyurethane, or other liquid repair resins
Ergonomic design ensures easy operation and user comfort
Clear barrel for visual inspection of resin quantity during operation
Compatible with most low-viscosity and medium-viscosity resins
Enables targeted filling and consolidation of narrow or hairline cracks
Disposable or reusable after cleaning (as appropriate)
Lightweight, robust, and portable; ideal for job site or laboratory use
Variety of nozzle sizes and lengths available for different applications
Typical Applications
Crack injection and repair in concrete, stone, brick, or masonry
Micro-filling of fine voids and delaminations in fragile structures
Laboratory testing or sampling with epoxy and other bonding resins
Restoration of historical buildings, monuments, or delicate architectural elements
Spot repair and precision grouting in construction and civil engineering
Handling & Usage Instructions
Prepare the resin (mix thoroughly as recommended by the manufacturer).
Draw up the resin into the syringe, ensuring no air bubbles remain.
Insert the nozzle into the crack, hole, or repair site.
Inject slowly and steadily, filling the void from the deepest point outwards.
Clean the syringe thoroughly after use if reusing; dispose of responsibly if not.
Quality Assurance
Manufactured under ISO 9001 and stringent internal QC
Each batch inspected for leakage, material quality, and usability
Compatible with all RBS-CONTECH epoxy, polyurethane, and specialty resins
Ordering & Support
For technical consultation, ordering, or custom product requests, contact:
Phone: +98-21-88070173, +98-21-88584906
Mobile: +98-9102333497, +98-9120916271, +98-9120916272
Email: clinicbeton.com(AT)gmail.com
Web: https://www.clinicbeton.com | https://www.rbs-contech.com
Note:
Different sizes, tip configurations, and professional kits are available through Clinic Beton Iran and RBS-CONTECH.
