BETOCRETE–K 10
Additive crystalizing waterproofing with super fluidity properties to concrete.
DESCRIPTION:
Betocrete k10 is a crystalline waterproofing admixture for concrete that provides integral waterproofing and reduces water demand, while increasing concrete strength and durability. The admixture reacts with moisture and forms insoluble crystals within the concrete pores and capillaries, providing permanent water and salt resistance. This results in the protection of the concrete and reinforcing steel, increasing the lifespan and durability of the structure.
During concrete curing, if there is a risk of shrinkage and water ingress, the admixture initiates the formation of new crystals, filling the voids and ensuring waterproofing and protection. The admixture is composed of synthetic polymers produced under controlled conditions, ensuring consistent quality. It is added directly to the fresh concrete mixture.
APPLICATION
The main applications of this product include:
Waterproofing of retaining walls
Water tanks and water treatment plants
Sewage and septic tanks
Elevator shafts
Water-retaining structures such as dams
Underground structures such as tunnels and subways
Parking garages
Large-scale concrete pours
Precast concrete parts
Bridges and related structures
Properties and benefits:
High-performance waterproofing
Waterproofing from all directions (positive and negative)
Protection of reinforced steel from corrosive salts such as chlorides, sulfates, and others
Effective reduction of water demand in concrete mixing.
Self-healing waterproofing for up to 400 microns of static cracks
Increased durability and lifespan of concrete structures
Resistance to both positive and negative water pressure up to 13 times
Improved pumpability and efficiency of concrete
Enhancement of all physical and mechanical properties of concrete
Reduced carbonation rate of concrete
Improved surface finish of concrete
Reduced risk of aggregate separation, water ingress, settlement, and erosion
Allows for long-distance concrete transportation
Non-flammable, non-combustible, non-toxic, chloride-free, and VOC-free.
three standards for chemical admixtures for concrete, specifically for
Waterproofing: ASTM C494 TYPE G, EN 934-2-TABLE 11.1/11.2, and ISIRI 2930 –TABLE 12.13.
"Properties Table:
State and Color: Dark brown liquid or taupe powder
Density at +1 at 20/28 ± 0/005 degrees
Air content: Less than 1%
Reduction in water content: Up to 20%
Setting time: Both initial and final setting times are delayed. These times depend on the amount of material used and the concrete mixing design.
Waterproofing and increasing the durability of concrete. All mechanical properties of concrete improve at all ages."
Compatibility:
It should not be mixed with other pre-mixed additives or used without the permission of the manufacturer.
It is recommended to consult with the technical unit of the green concrete company (Iran's technical and specialized concrete clinic) in such situations.
If this material is used excessively, it will delay the setting time of concrete, and in such cases, it is necessary to prevent the evaporation of water.
DIRECTION OF USE :
Betocrete K-10 should be added to the fresh concrete mix.
It should not be added directly to the cement or dry mix.
Proper mixing should be ensured by using an automatic mixer.
Dosage:
The consumption of this material depends on the type of cement, mixing design, quality of materials used, environmental temperature, and technical specifications. Therefore, a test and trial error must be performed to determine the appropriate consumption level. The approximate consumption rate is between 2% and 3% of the cement weight.
Cleaning:
All tools and equipment can be easily cleaned with water.
The storage:
The material can be stored in its original packaging for up to 12 months without degradation, as long as it is kept at room temperature and away from high and low temperatures. The material does not produce any harmful fumes during use.
Packaging:
The powdered form of the material is packaged in 25-kilogram bags, while the liquid form is packaged in 20-liter or 220-liter cans. The technical department of the Rayan Baton Green Company (Iranian Technical and Specialized Concrete Clinic) is available for consultation and technical services to ensure proper use of the material.
